Scintag XDS2000 Powder Diffractometer

A close up of the XRD powder instrument.

Location

M&M 629

Calendar Name

ACMAL-XRD Powder

Access Type

Logbook

Remote Capability

Yes

Instrument Details

The Scintag XDS2000 powder diffractometer is configured with a graphite monochromater and IBM compatible workstation running Scintag DMSNT software in Windows NT environment.

Capabilities

Remote Training and Collaboration

  • New cameras installed in both the instrument lab and sample preparation lab.
  • Huskycast (Panopto) recording for both cameras and lab computer monitors.
  • Zoom sharing available in both labs and computer monitors.

Instrumentation

This theta-theta configured goniometer permits automated collection of intensity vs. scattering angle scans. Data reduction schemes include unit cell determination, pattern indexing, precision lattice parameter determination, and Reitveld analysis. Crystalline compounds can be identified through indexing with the built-in JCPDS powder diffraction database.
